🚜 YTO-NLX1604 Tractor
High-Power 160 HP Tractor for Heavy-Duty Farming Operations
🌟 Key Features
- 160 HP Turbocharged & Intercooled Engine for maximum productivity
- Heavy-Duty 4WD ensures superior traction on tough terrains
- 16F + 8R Synchronized Transmission with shuttle shift
- High-Capacity Hydraulics with up to 5,500 kg lifting power
- Independent Dual-Speed PTO (540/1000 rpm) for versatile operations
- Premium Comfort Cabin with AC, suspension seat, and ergonomic controls
📊 Technical Specifications
General
- Model: YTO-NLX1604
- Type: Agricultural Wheeled Tractor
- Drive: 4WD
- Rated Power: 118 kW (160 HP)
- PTO Power: ~95 kW
- Operating Weight: ~5,200 – 5,600 kg
- Wheelbase: 2,950 mm
- Overall Dimensions: ~4,950 × 2,350 × 3,150 mm
Engine
- 6-Cylinder, Turbocharged & Intercooled Diesel
- Rated Speed: 2,200 rpm
- Fuel Injection: High-pressure direct injection
- Cooling System: Water-cooled
- Fuel Tank Capacity: ~280 L
Transmission & Drive
- Clutch: Dual-stage, independent
- Gearbox: 16 Forward + 8 Reverse (synchronized shuttle shift)
- Forward Speed Range: 2.5 – 35 km/h
- Reverse Speed Range: 2.0 – 15 km/h
- Differential Lock: Electro-hydraulic
- Steering: Hydrostatic power steering
PTO & Hydraulics
- PTO Type: Independent, 540/1000 rpm dual speed
- PTO Power: ~95 kW
- Hydraulic Flow: 70 – 75 L/min
- 3-Point Hitch: Category II / III
- Lifting Capacity: 5,000 – 5,500 kg
- Remote Valves: 2 – 4 optional
Axles & Wheels
- Front Axle: Heavy-duty oscillating 4WD
- Rear Axle: Planetary reduction
- Standard Tires: Front 14.9–28 / Rear 18.4–38
Brakes & Safety
- Service Brakes: Hydraulic wet disc brakes
- Parking Brake: Mechanical hand lever
- Safety: ROPS/FOPS-certified cabin, engine kill switch
Operator’s Cabin
- Fully enclosed, ergonomic design
- Air-conditioning & heating system
- Adjustable suspension seat
- Digital instrument dashboard
- Noise & vibration reduction system
Electrical
- Battery: 12V, 150Ah
- Alternator: 14V, 1.5 kW
- Lighting: Headlights, work lamps, hazard indicators
✅ Why Choose YTO-NLX1604?
Built for large-scale farming, the YTO-NLX1604 combines high horsepower,
superior durability, and operator comfort. With its strong hydraulic system, versatile PTO,
and premium cabin, it’s the perfect partner for ploughing, tillage, seeding, and
transportation tasks.
