🚜 ATS Tractor 290 Manual 77HP
The ATS Tractor 290 is a powerful, reliable, and fuel-efficient machine designed for farming, heavy-duty fieldwork, and transport. Below is a detailed breakdown of its general specifications, engine details, transmission, hydraulic lift, PTO, braking system, and equipment options.
🔧 General Specifications
| Nominal HP | 77 HP @ 2250 rpm |
| Max Torque | 273 Nm @ 1600 rpm |
| Max PTO Power | 63 HP @ 2200 rpm |
| Overall Length | 3810 mm (150 in) |
| Overall Width | 2032 mm (80 in) |
| Height (Silencer) | 2253 mm (99 in) |
| Wheelbase | 2310 mm (90 in) |
| Turning Radius | 4275 mm (168 in) |
| Oil Capacity | 7.5 L (1.98 US gal) |
| Coolant Capacity | 14 L (3.7 US gal) |
| Fuel Tank | 87.0 L (23.8 gal) |
| Steering | Manual |
⚙️ Engine
| Type | 440TN (A4.248) |
| No. of Cylinders | 4 – Inline |
| Fuel Type | Diesel |
| Injection | Direct |
| Displacement | 4.06 L (248 cu.in) |
| Bore x Stroke | 101 x 127 mm (4 x 5 in) |
| Aspiration | Natural |
| Compression Ratio | 16.0 : 1 |
| Cooling System | Water Cooled |
| Cold Starting Aid | Intake Heater Plug |
| Governed Speed | Low Idle: 750 rpm High Idle: 2150 rpm (No Load) Rated: 2000 rpm (Full Load) |
🚜 Transmission
- Type: Sliding Spur
- Gears: 8 Forward & 2 Reverse
- Speed: Forward: Up to 30 km/h (18.64 mph) – Reverse: Up to 14.50 km/h (8.6 mph)
💨 Hydraulic Lift
- Type: Open Center
- Max Pressure: 207 Bar (3000 PSI)
- Max Lift Capacity: 2150 Kg (4,730 lbs)
- Clutch: Dual, 12-inch
⚡ Power Take Off (PTO)
- Type: Live
- PTO Speed: 540 rpm
- Shaft Diameter: 35 mm (1.38 in)
- No. of Splines: 6
🛑 Braking System
- Brake Type: Oil Immersed Multi Disc
- Actuation: Foot Operated Dual Pedal
- Parking Brake: Hand Operated
- Differential Lock: Mechanical
🔋 Electrical System
- Voltage: 12V
- Battery Size: 100 AH
- Lighting: Halogen headlamps, turn signals, rear combination lights, fender-mounted rear lamp
- Indicators: Oil Pressure, Battery Charging, Fuel Level, Odometer, Water Temperature, Tachometer
🛞 Wheels & Tires
Front Tire: 7.50-16 (6PR) Pressed
Rear Tire: 16.9/14-30 (14PR) Pressed
📦 Equipment
Standard
- Front weight frame (without weight)
- Chain stabilizer
- Check chain
- Standard toolbox (with tools)
- Cat I & II Balls
Optional
- Front end weights
- Swinging drawbar
- Sun canopy
- Pintal hook
- 9-hole drawbar
- LED headlights
- Rear tire 13.6-38
🎨 Colour Options
Available in Red and Blue.
